Oblique Push Type High Speed Circular Sawing Machine

The Oblique Push Type High Speed Circular Sawing Machine is engineered for precision and durability in cutting bars and tubes. Its high-rigidity frame structure resists deformation under high cutting forces, ensuring stable, accurate cuts. The machine features an active oblique-feed material feeding system, which prevents surface damage and enhances feeding precision. At its heart is a high-rigidity, highly accurate spindle gearbox, equipped with a backlash-elimination mechanism—this stabilizes the plunge during cutting and dramatically extends tool life.

Operation is simplified with a one-button start and an intuitive dialogue-style touch input interface, enabling fast setup and minimal operator training. This saw is suitable for a wide range of materials: stainless steel, tool steel / mold steel, mild or ordinary steel, aluminum and copper alloys.

Optional Device
Oil mist collector
With heated hydraulic station
Cluster automatic rack
Long material to undertake devices
Robot connection device

Inquiry

Circular Saw Model Number	HSM - 50S	HSM - 55X	H70XS	HSM - 80X
Feed Mode	Oblique push type	Oblique push type	Oblique push type	Oblique push type
Model Positioning	Heavy-duty engine	Standard machine	Heavy-duty engine	Heavy-duty engine
Suitable Cutting Materials	Stainless steel/alloy steel	Ordinary steel/copper alloy/aluminum alloy	Stainless steel/alloy steel	Ordinary steel/copper alloy/aluminum alloy
Round Bar (mm)	10-50	10 - 55	10 - 70	20 - 80
Square Materials (mm)	10-30	10 - 35	10 - 50	20 - 55
Tail length (mm)	70 + cut length	70 + cut length	70 + cut length	70 + cut length
Single Feed Length (mm)	550	550	550	780
Feeding Accuracy (mm)	＋－0.05	＋－0.05	＋－0.05	＋－0.05
Saw Blade Thickness/Blade Thickness	1.75 - 2.0	1.75 - 2.0	1.75 - 2.0	1.75 - 2.0
Saw Blade Outer Diameter/Inner Diameter (mm)	Φ250 - 32	Φ250 - 32	Φ285 - 32	Φ315 - 32
Saw Blade Pin Hole (mm)	Φ63 - 11	Φ63 - 11	Φ63 - 11	Φ63 - 11
Saw Blade Speed (rpm)	80 - 150	110 - 200	60 - 135	100 - 180
Hydraulic Motor (kw)	1.5/4P	1.5/4P	1.5/4P	1.5/4P
Oil Pump Pressure (mpa)	7.0	7.0	7.0	7.0
Tank Volume(L)	50	50	60	60
Feeding Mode	Servo + screw + sliding shaft	Servo + screw + sliding shaft	Servo + screw + sliding shaft	Servo + screw + sliding shaft
Clamping Mode	Hydraulic cylinder clamping	Hydraulic cylinder clamping	Hydraulic cylinder clamping	Hydraulic cylinder clamping
Operating Voltage (V)	380	380	380	380
Main Motor Specification (kW)	5.5/6P	5.5	7.5/6P	11/4P
Feed Motor Specification (kW)	Servo 1.8	Servo 1.8	Servo 1.8	Servo 1.8
Feeding Motor Specifications (kW)	Servo 0.85	Servo 0.85	Servo 0.85	Servo 0.85
Chip - Discharge Motor Specifications (kW)	Hydraulic type	Hydraulic type	0.4/4P	0.4/4P
Machine Weight (kg)	1500	1500	1600	3000
Machine Size (Length × Width × Height) (mm)	1780×1500×1730	1780×1500×1730	1780×1500×1650	2300×1760×1900
